How StartER Solves the Express + Vite SSR Puzzle

Have you ever tried to combine Express and Vite for server-side rendering in a React application?

If so, you’ve probably encountered the challenge of managing two separate servers and making them work together smoothly.

In this post, I’ll walk you through how StartER solves this problem with a “one server” approach that not only simplifies development but also enables powerful Server-Side Rendering (SSR) capabilities.

The Problem: Two Servers, One Application

When building a modern web application with React and Express, you typically have:

• A Vite development server handling hot module replacement (HMR) and React-specific features
• An Express backend server managing API routes and server-side logic

Managing these as separate servers creates unnecessary complexity:

• You need proxy configurations
• Communication between servers becomes cumbersome
• Local development requires running multiple processes
• Deployment gets more complicated

StartER’s Solution: One Server to Rule Them All

StartER takes a different approach by attaching a Vite development server to the Express application server, creating a single unified server. This architecture brings several benefits:

• Simplified development workflow
• Cleaner codebase structure
• Elimination of complex proxy setups
• Streamlined deployment

But the most powerful benefit? It enables Server-Side Rendering out of the box.

How StartER Implements SSR with Express and Vite

The key to StartER’s SSR implementation is how it integrates Vite’s middleware mode with Express while leveraging React Router’s static rendering capabilities.

The Core Structure

.
├── index.html
├── server.ts             # Main application server
└── src
    ├── entry-client.tsx  # Mounts the application on a DOM element
    ├── entry-server.tsx  # Renders the application using Vite's SSR API
    └── react
        └── routes.tsx    # Entry point for React code (client/server agnostic)

This structure separates the concerns while maintaining a cohesive application architecture.

Setting Up the Development Server

The magic starts in server.ts where we configure Vite in middleware mode:

import express from "express";
import { createServer as createViteServer } from "vite";

const app = express();
const isProduction = process.env.NODE_ENV === "production";

if (!isProduction) {
  // Create Vite server in middleware mode
  const vite = await createViteServer({
    server: { middlewareMode: true },
    appType: "custom",
  });

  // Use vite's connect instance as middleware
  app.use(vite.middlewares);

  app.use(/(.*)/, async (req, res, next) => {
    // Handle SSR rendering
    // (We'll explore this next)
  });
}

By using middlewareMode: true and appType: "custom", we tell Vite to let our Express server take control while still providing all its development features.

Server-Side Rendering Implementation

The real SSR magic happens in the catch-all route handler and the entry-server.tsx file. StartER uses React Router’s static handlers and renderToPipeableStream for efficient rendering with Suspense support:

app.use(/(.*)/, async (req, res, next) => {
  const url = req.originalUrl;
  const indexHtml = fs.readFileSync("index.html", "utf-8");

  // Transform HTML with Vite plugins
  const template = await vite.transformIndexHtml(url, indexHtml);

  // Load the server entry module
  const { render } = await vite.ssrLoadModule("/src/entry-server");

  // Render the app HTML
  await render(template, req, res);
});

And in entry-server.tsx:

import { Transform } from "node:stream";
import { renderToPipeableStream } from "react-dom/server";
import { createStaticHandler, createStaticRouter, StaticRouterProvider } from "react-router";

import routes from "./react/routes";

const { query, dataRoutes } = createStaticHandler(routes);

export const render = async (template, req, res) => {
  // Get routing context
  const context = await query(
    new Request(`${req.protocol}://${req.get("host")}${req.originalUrl}`)
  );

  // Create a static router for SSR
  const router = createStaticRouter(dataRoutes, context);

  // Stream the rendered content
  const { pipe } = renderToPipeableStream(
    <StaticRouterProvider router={router} context={context} />
  );

  // Respond with streamed HTML
  res.status(200).set("Content-Type", "text/html; charset=utf-8");

  const [htmlStart, htmlEnd] = template.split("<!--ssr-outlet-->");
  res.write(htmlStart);

  const transformStream = new Transform({
    transform(chunk, encoding, callback) {
      res.write(chunk, encoding);
      callback();
    },
  });

  pipe(transformStream);
  transformStream.on("finish", () => {
    res.end(htmlEnd);
  });
};

This streaming approach has several benefits:

• Support for React’s <Suspense> on the server
• Faster Time-To-First-Byte (TTFB)
• Progressive rendering of content
• Better user experience, especially on slower connections

Production Deployment

For production, StartER uses a two-part build process:

{
  "scripts": {
    "build:client": "vite build --outDir dist/client",
    "build:server": "vite build --outDir dist/server --ssr src/entry-server"
  }
}

The server code then loads the pre-built SSR bundle in production mode instead of using Vite’s development-time ssrLoadModule.

Why Choose StartER for Your Next Project?

StartER is more than just an SSR implementation – it’s a complete web application framework designed for educational purposes that doesn’t sacrifice power or flexibility.

Key Benefits:

• Educational Focus: Perfect for beginners and those advancing their skills
• Seamless Development: One server approach eliminates complexity
• Modern Stack: React + Express + Vite + SSR
• Production Ready: Optimized build process for deployment
• Best Practices: Combines the best packages in the JS ecosystem

Whether you’re learning web development or building a production application, StartER provides a solid foundation that lets you focus on what matters – building your application features.

Get Started with StartER

Ready to try this “one server” approach for your next React + Express project?

Check out StartER on GitHub and give it a star if you find it useful!

The full implementation details for the SSR functionality can be found in:

• server.ts
• entry-server.tsx
• entry-client.tsx

What web development challenges are you facing that StartER might help solve? Open a discussion to let me know!
